The iBasso Audio AMP16 is a revolutionary amplifier card exclusive to the DX340 player, merging the soulful glow of vacuum tubes with modern solid-state precision. Powered by two Raytheon JAN6418 tubes—relics of North American military labs—it awakens their potential with a 22.5V anode voltage, infusing music with a timeless metallic resolve. Dual TUBE and Class AB modes offer a sonic multiverse: TUBE mode recalls the 1950s golden age with warm, misty harmonics, while Class AB unleashes transistor-driven clarity free of noise or interference. Its lavish design includes four TI op-amps and four BUF634A buffers, forming an eightfold sonic oracle that refines audio into a celestial masterpiece. With 2000mW per channel and support for 12V DC-IN, the AMP16 conquers even the most demanding headphones, while the JRC hardware volume control tames noise with 100-step precision. Every tube pair is hand-matched using an APx555 analyzer, ensuring harmonic distortion remains imperceptible.
| Parameter | Details |
|---|---|
| Model | iBasso Audio AMP16 |
| Product Type | Amplifier Card (DX340 Exclusive) |
| Tubes | Dual Raytheon JAN6418 (Hand-Matched) |
| Circuitry | 4x TI Op-Amps + 4x BUF634A Buffers |
| Modes | TUBE / Class AB (Switchable) |
| Outputs | 4.4mm Balanced + 3.5mm Single-Ended (Pentaconn) |
| Power Supply | 12V DC-IN Supported |
| Class AB - 4.4mm Balanced | Output: 8.3Vrms (Super Gain), 2000mW @ 32Ω (12V DC-IN); THD+N: -117dB; SNR: 122dB |
| Class AB - 3.5mm Single-Ended | Output: 4.1Vrms (Super Gain), 500mW @ 32Ω (12V DC-IN); THD+N: -108dB; SNR: 120dB |
| TUBE - 4.4mm Balanced | Output: 7.5Vrms (Super Gain), 1500mW @ 32Ω (12V DC-IN); Freq. Response: 20Hz–40kHz +1dB |
| TUBE - 3.5mm Single-Ended | Output: 3.75Vrms (Super Gain), 400mW @ 32Ω (12V DC-IN); Freq. Response: 20Hz–40kHz +1dB |
