iBasso DC07PRO Portable Decoder
4Pcs CS43131 Chip 4.4mm Balanced/3.5mm Single-ended USB DAC & AMP
Description
The iBasso DC07PRO is a portable decoder featuring four CS43131 DAC chips, offering high-resolution audio performance with both 4.4mm balanced and 3.5mm single-ended outputs. This compact and powerful DAC & AMP supports PCM up to 32bit/768kHz and DSD512, making it an ideal choice for audiophiles looking for top-notch sound quality in a portable form factor.
Features
- High-Performance DAC Chips: Equipped with 4 CS43131 DAC chips from Cirrus Logic for exceptional audio performance.
- PCM and DSD Support: Supports PCM up to 32bit/768kHz and native DSD512 for high-definition audio playback.
- Versatile Outputs: Features both 4.4mm balanced and 3.5mm single-ended headphone outputs.
- FPGA Algorithm: Utilizes a self-developed FPGA algorithm and KDS femtosecond crystal oscillator for precise signal processing and reduced clock jitter.
- OLED Display: Includes a 0.96-inch OLED display for easy control and function settings.
- High Output Power: Provides powerful thrust to drive various wired headphones on the market.
- Low Power Consumption: Synchronous rectification technology with a power conversion efficiency of up to 94% and overall power consumption as low as 80mA.
- Ultra-Low Noise LDO: Ensures the purity of the power supply for a purer sound experience.
- Premium Build Quality: CNC machined aluminum alloy body with dual tempered glass panels for a sophisticated look and feel.
- Compatible with iPhone: Low power consumption design ensures compatibility with iPhone without triggering power protection.
- SPDIF Output: Supports SPDIF output up to 32bit/768kHz for use as a professional digital transport.
General Parameters
- DAC Chip: 4 CS43131 chips
- PCM: Up to 32bit/768kHz
- DSD: Maximum Native DSD 512x
- Weight: 23g
- Size: 59mm * 23.5mm * 12.5mm
- Color: Black, Silver
Packaging Accessories
- 1 * DC07PRO
- 1 * Type C to Type C line
- 1 * Type C to Lightning cable
- 1 * USB-C to A adapter
- 1 * Instruction manual
Technical Parameters of DC07Pro
4.4mm Balanced Output
- THD+N: -120.2dB(0.000098%)@1kHz 300Ω Load
- Output Level: 2.8Vrms (Low Gain), 3.5Vrms (Mid Gain), 4Vrms (High Gain)
- Output Power: 510mW+ 510mW@16Ω, 430mW+ 430mW@32Ω
- Signal to Noise Ratio: 134dBA
- Dynamic Range: 134dBA
- Separation Degree: 142dB
- Frequency Response: 10Hz~80kHz -0.5dB
- Bottom Noise: 0.85uV
3.5mm Single Ended Output
- THD+N: -116dB(0.00017%)@1kHz 300Ω Load
- Output Level: 1.4Vrms (Low Gain), 1.73Vrms (Mid Gain), 2Vrms (High Gain)
- Output Power: 210mW+ 210mW@16Ω, 118mW+ 118mW@32Ω
- Signal to Noise Ratio: 129dBA
- Dynamic Range: 129dBA
- Separation Degree: 136dB
- Frequency Response: 10Hz~75kHz -0.5dB
- Bottom Noise: 0.76uV
Advanced Audio Processing
The DC07Pro features a self-developed FPGA algorithm and KDS femtosecond crystal oscillator to build a small tail independent audio master, achieving signal recombination and synchronized global clock, reducing clock jitter caused by the USB bus, eliminating jitter and waveform distortion on the audio bus, and making the sound purer.
With four flagship CS43131 DAC chips from Cirrus Logic, optimized through self-developed FPGA technology, the DC07Pro supports a wide frequency response range, high dynamic range, and ultra-low noise, providing an unparalleled audio experience.
