SMSL DS20 Hi-Res Portable DAC & Headphone Amplifier

SMSL DS20 Hi-Res Portable DAC & Headphone Amplifier

Regular price $189.99 USD
Regular price $189.99 USD Sale price $189.99 USD
Save 0% Sold out
Shipping calculated at checkout.
Color

Shipping to

Estimated delivery on

Canada, Mexico, Romania, United States: import duty of 10 USD

SMSL DS20 Portable DAC & Headphone Amplifier

Symphony in the Palm | High-Performance Hi-Res Audio

Description

The SMSL DS20 is a portable DAC and headphone amplifier that not only boasts visual appeal but also delivers professional-grade sound quality. With precision decoding and a fully balanced amplifier circuit, the DS20 offers superior sound performance. Powered by 4x Cirrus Logic CS43131 DAC chips and featuring MQA full decoding, this device supports PCM up to 32bit/768kHz and DSD up to 256, offering you an unparalleled listening experience.

Features

  • Quad Decoding Chip Set: 4x Cirrus Logic CS43131, ensuring high-quality sound with support for MQA full decoding, PCM up to 32bit/768kHz, and DSD up to DSD256.
  • Fully Balanced Headphone Amplifier: Provides clean, distortion-free audio with advanced circuit design.
  • Latest Audio Decoding Chip: New 3rd generation XMOS XU-316 for efficient audio processing.
  • Dedicated Audio Clock Circuit: Reduces clock jitter, minimizes tonal distortion, and enhances soundstage resolution and micro-details.
  • Dual USB Mode Selection: USB 1.1/2.0 switchable for broader compatibility, including PS5 and Nintendo Switch.
  • Low Noise Design: Precision components, including resistors and capacitors, to maintain clear and accurate audio.
  • Compact & Durable: Sleek full-metal body and lightweight design (275g), perfect for on-the-go use.

Specifications

  • DAC Chip: Cirrus Logic CS43131 x4
  • Input: USB Type-B
  • Outputs: 3.5mm Line Out, 3.5mm HP Out, 4.4mm Balanced HP Out
  • Output Power: 500mW @ 32Ω, 350mW @ 64Ω, 240mW @ 150Ω, 120mW @ 300Ω, 60mW @ 600Ω
  • Output Level: 3 VRMS (3.5mm HP), 6 VRMS (4.4mm HP)
  • Output Impedance: Near 0Ω (Headphone Output)
  • Dynamic Range: 126dB (both 3.5mm and 4.4mm outputs)
  • SNR: 126dB (both 3.5mm and 4.4mm outputs)
  • THD+N: 0.00029%
  • Battery Capacity: 6000mAh (22.2Wh)
  • Size: 71mm × 17mm × 118.5mm (WxHxD)
  • Weight: 275g
  • USB Compatibility: Windows 7/8/8.1/10/11, Android, iOS, macOS, Linux, PS4, PS5, Nintendo Switch

Note

The SMSL DS20 is designed for audiophiles, gamers, and music lovers who demand high-performance audio in a compact and durable form. With advanced decoding technology, precision components, and a balanced amplifier circuit, the DS20 ensures a premium listening experience wherever you go.

SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier

SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier SMSL DS20 Hi-Res portable DAC/AMP Headphone Amplifier
